Fix Windows Error 809, L2TP/IPSec VPN

In recent years, the concept of remote work, or working from home, has seen a significant surge in popularity. As organizations adapt to the evolving landscape of employment, an increasing number of employees now find themselves working from home offices, relying on Virtual Private Networks (VPNs) to establish secure connections with their respective company servers. This shift to remote work has brought about several technological challenges, one of which is the proper configuration and usage of VPNs

Setting up a VPN can often be more complex in practice than what the documentation suggests, leading to a myriad of issues and roadblocks. Many remote workers encounter difficulties in establishing and maintaining a stable VPN connection, and this has become a common concern in the digital workspace.

The personal experience I’m sharing here represents one such instance, illuminating a specific VPN-related issue I encountered during my remote work journey.

Some technical stuff

By default, the Windows client and the Windows Server operating system do not support Internet Protocol security (IPsec) network address translation (NAT) Traversal (NAT-T) security associations to servers that are located behind a NAT device. Therefore, if the virtual private network (VPN) server is behind a NAT device, a Windows-based VPN client computer, or a Windows Server-based VPN client computer cannot make a Layer Two Tunneling Protocol (L2TP)/IPsec connection to the VPN server. This scenario includes VPN servers that are running Windows Server 2008/R2, Windows Server 2012/16, and Microsoft Windows Server 2003.

Because of how NAT devices translate network traffic, you may experience unexpected results when you put a server behind a NAT device and then use an IPsec NAT-T environment. Therefore, if you must have IPsec for communication, it is recommended that you use public IP addresses for all servers that you can connect to from the Internet. However, if you have to put a server behind a NAT device and then use an IPsec NAT-T environment, you can enable communication by changing a registry value on the VPN client computer and the VPN server.

The Solution

You will need to create and configure the AssumeUDPEncapsulationContextOnSendRule registry value using the windows registry.

Disclaimer: Editing the Windows Registry file is a serious undertaking. A corrupted Windows Registry file could render your computer inoperable, requiring a reinstallation of the Windows 10 operating system and potential loss of data. Back up the Windows 10 Registry file and create a valid restore point before you proceed.

To apply the fix follow these steps:

1. Log on to the Windows client computer as a user who is a member of the Administrators group.
2. Click Start, point to All Programs, click Accessories, click Run, type regedit, and then click OK. If the User Account Control dialog box is displayed on the screen and prompts you to elevate your administrator token, click Continue.
3. Locate and then click the following registry subkey: HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\PolicyAgent
4. On the Edit menu, point to New, and then click DWORD (32-bit) Value.
5. Type AssumeUDPEncapsulationContextOnSendRule, and then press ENTER.
6. Right-click AssumeUDPEncapsulationContextOnSendRule, and then click Modify.
7. In the Value Data box, type 2.
   A value of 2 configures Windows so that it can establish security associations when both the server and the Windows Vista-based or Windows Server-based VPN client computer are behind NAT devices.
8. Click OK, and then exit Registry Editor.
9. Restart the computer.
