How TCP Buffer Size and Jumbo Frames Affect Large File Download Speed

I was working on a service that transmit very large files, sometimes hundreds of gigabytes. We use a high-speed network, up to 3–4 GB/s (≈ 32 Gbps). At first, I thought this was enough. But when I tested, the download speed was much slower than expected. After digging into it, I figured TCP buffer size could be related. In this post, I’ll share how I tuned it and what I learned.

1. TCP Buffers and Window Size

When you use TCP to send or receive data, the kernel stores that data in memory buffers:

• Send buffer (SO_SNDBUF): For data waiting to be sent.
• Receive buffer (SO_RCVBUF): For data received but not yet read by the app.

TCP also advertises a window size, which is how much unacknowledged data can be “in flight.”

If your buffer/window is too small, TCP will not fully use the link speed, no matter how fast your NIC is.

2. Bandwidth-Delay Product (BDP)

The buffer size you need depends on both network bandwidth and round-trip time (RTT):

BDP = Bandwidth (bytes/sec) × RTT (seconds)

This is the minimum TCP window size needed to fully use the connection.

Example:

Bandwidth           RTT       Required TCP Window
-----------------   -------   -------------------
4 GB/s (≈ 32 Gbps)  1 ms      4 MB
4 GB/s (≈ 32 Gbps)  10 ms     40 MB
4 GB/s (≈ 32 Gbps)  20 ms     80 MB

So, even on a 1 ms RTT link, you already need 4 MB of TCP window per stream to reach full speed. Many OS defaults are far smaller (256 KB or 1 MB).

3. Why Jumbo Frames Help

MTU (Maximum Transmission Unit) is the maximum packet size on the network.

• Standard Ethernet MTU: 1500 bytes
• Jumbo frame MTU: 9000 bytes

With a jumbo MTU, each packet carries 9 KB of data instead of 1.5 KB.
Benefits:

1. Fewer packets per second → Less CPU load on sender and receiver.
2. Lower interrupt load on NICs → Better efficiency.
3. Less protocol overhead → Higher effective throughput.

Jumbo frames do not change the TCP window calculation. You still need large buffers to keep the pipe full. Jumbo MTU just reduces per-packet cost so your CPU can keep up with multi-GB/s speeds.

4. Linux Tuning

On Linux, buffer size is automatically scaled, but only up to net.core.rmem_max and net.core.wmem_max. To achieve 3–4 GB/s, you often need to raise these limits.

sysctl -w net.core.rmem_max=134217728
sysctl -w net.core.wmem_max=134217728
sysctl -w net.ipv4.tcp_rmem='4096 87380 134217728'
sysctl -w net.ipv4.tcp_wmem='4096 65536 134217728'

Explanation:

• rmem_max, wmem_max: Max size of receive/send buffers (128 MB here).
• tcp_rmem, tcp_wmem: Min, default, and max sizes for TCP buffers.
• TCP window scaling (RFC 1323) must be enabled (Linux enables it by default).

You can check buffer sizes like this:

cat /proc/sys/net/core/rmem_max
cat /proc/sys/net/core/wmem_max

5. Testing with iperf3

To verify improvements, I use iperf3:

iperf3 -c <server_ip> -P 4

-P 4 runs 4 parallel streams. If one stream can’t saturate the link because of buffer limits, multiple streams help. After tuning, one stream should be enough.

Lessons Learned

1. TCP window scaling and large buffers are required to fully use a high-speed link.
2. BDP is the key formula: buffer = bandwidth × RTT.
3. Jumbo frames reduce CPU and packet overhead, but you still need to tune TCP.
4. Linux autotuning works well if you raise system max limits.
5. Always measure with iperf3 and adjust step by step.

Quick Checklist for Large File Download Performance

• Measure RTT between your client and server.
• Calculate BDP: bandwidth × RTT.
• Increase rmem_max and wmem_max to at least 2× BDP.
• Enable jumbo MTU if your whole network path supports it.
• Re-test with iperf3.
