Ionic 6 Made Easy: Implementing PDF Downloads with Capacitor

To add a PDF download feature in your Ionic 6 application using Capacitor, the steps are largely similar for both iOS and Android, with the primary difference being the permissions required for each platform. Below is a detailed guide tailored specifically for iOS, but keep in mind that about 80% of the steps are identical to those for Android, with adjustments mainly in the permissions section.

Step 1: Install Required Plugins

First, ensure that you have the required plugins installed in your Ionic project. If you haven’t done so already, run the following commands:

npm install @capacitor/filesystem
ionic cap sync

This installs the Capacitor Filesystem plugin, which allows you to read and write files on the device.

Step 2: Update Main.ts

Next, you need to import the Filesystem plugin in your main.ts file and add it to your providers array:

// Import the Filesystem plugin
import { Filesystem, Directory } from ‘@capacitor/filesystem’;
// Add it to your providers array
providers: [
 File,
],

Step 3: Save PDF Data

If you have base64 encoded PDF data, you can use the following method to save it:

// param 1 is your base64 content
// param 2 is custom file name
// Call this method where you want to trigger save PDF event
this.savePdf(resultData.reportPDF, 'sample-report.pdf');
// Method to save PDF
// fileName : only file file name
async savePdf(base64String: string, fileName: string) {
    try {
        // Remove prefix if present
        const base64Data = base64String.startsWith('data:application/pdf;base64,')
            ? base64String.split(',')[1]
            : base64String;
// Write the file to the application's data directory
        const result = await Filesystem.writeFile({
            path: '<< folder name >>'+fileName,
            data: base64Data,
            directory: Directory.Documents,
            recursive: true,
        });
console.log('File saved at:', result.uri);
        // Downloaded file url will be folder/sample-report.pdf
        this.downloadedFileURL = '<< folder name >>/'+fileName;
        this.openPdfFile();
    } catch (error) {
        console.error('Error saving file:', error);
        throw error;
    }
}

This method handles saving a base64 encoded PDF to the device’s Documents directory.

Step 4: Install File Opener Plugin

To open the saved PDF file, you’ll need an additional plugin. Install it using:

npm install @awesome-cordova-plugins/file-opener
npm install cordova-plugin-file-opener2
ionic cap sync

Step 5: Update Main.ts for File Opener

Import the FileOpener plugin and add it to your providers:

// Import FileOpener plugin
import { FileOpener } from '@awesome-cordova-plugins/file-opener/ngx';
// Add it to your providers array
providers: [
  FileOpener,
],

Step 6: Open Local Downloaded File

You can now implement a method to open the downloaded PDF file:

async openPdfFile() {
    try {
        const filePath = await Filesystem.getUri({
            path: this.downloadedFileURL,
            directory: Directory.Documents,
        });
console.log('Opening file at:', filePath.uri);
this.fileOpener.open(filePath.uri, 'application/pdf')
            .then(() => console.log('File opened successfully'))
            .catch((error) => console.error('Error opening file:', error));
    } catch (error) {
        console.error('Error fetching file URI:', error);
    }
}

This method retrieves the URI of the saved PDF and opens it using the default PDF viewer on the device.

Step 7: List All Downloaded Files

If you want to get a list of all downloaded files in a specific folder, implement this method:

async listAllDownloadedFiles() {
    try {
        const result = await Filesystem.readdir({
            path: '<< folder name >>', // Specify your folder name here
            directory: Directory.Documents,
        });
console.log('Files in provided folder:', result.files);
        return result.files; // Returns an array of file names
    } catch (error) {
        console.error('Error reading folder:', error);
        throw error;
    }
}

This function reads all files from a specified directory within the Documents folder.

Step 8: Add Permissions for iOS

For iOS applications, you need to add a usage description in your Info.plist file:

<key>NSDocumentsUsageDescription</key>
<string>App needs access to documents for audio processing.</string>

This informs users why your app requires access to their documents.

By following these steps, you can successfully implement a feature in your Ionic application that allows users to download and view PDF files. This enhances user experience by providing easy access to important documents directly within your app.
